What is meant by open die forging?

2023-10-18

Open die forging, also known as free forging or smith forging, is a metal forging process that involves the shaping and deformation of a metal workpiece between two flat or slightly contoured dies. In open die forging, the workpiece is not entirely enclosed within the dies, allowing for greater flexibility in shaping and forming large and complex parts.

Here are the key features and steps involved in open die forging:

1. Workpiece Preparation: The process begins with the preparation of a heated metal workpiece, often a billet or ingot. The workpiece is usually heated to a temperature suitable for forging, which can vary depending on the type of metal and its properties.

2. Die Selection and Setup: In open die forging, two dies are used - the top die (hammer) and the bottom die (anvil). The dies can be flat or have a slight contour to impart a desired shape or deformation. The dies are typically made of steel or another durable material capable of withstanding the forces and pressures involved in the forging process.

3. Shaping and Deformation: The heated workpiece is positioned on the bottom die, and the top die is brought down to apply pressure and force on the workpiece. The hammer or forging machine strikes the top die, deforming the workpiece and shaping it according to the desired form. The process may involve multiple strikes or passes to achieve the desired shape and dimensions.

4. Reheating and Repeating: Depending on the complexity of the part and the material being forged, the workpiece may need to be reheated between strikes to maintain its malleability. This reheating process ensures that the workpiece remains at an optimal forging temperature throughout the forging operation.

5. Finishing and Trimming: Once the desired shape is achieved, the forged part may undergo additional post-forging operations, such as trimming, machining, or surface finishing, to remove any excess material, refine dimensions, and improve the surface quality of the part.

Open die forging offers several advantages, including:

- Flexibility and versatility: Open die forging allows for the production of large and complex parts that may not be feasible with other forging methods.

- Improved mechanical properties: The forging process enhances the strength, toughness, and structural integrity of the forged parts, resulting in superior metallurgical properties.

- Cost-effectiveness: Open die forging can be a cost-effective method for producing forgings, especially for larger parts, as it typically requires less tooling and equipment compared to closed die forging.

Open die forging is commonly used in various industries, including heavy machinery, oil and gas, aerospace, power generation, and defense, where large and custom-shaped parts are required. The process offers flexibility, customization, and the ability to achieve high-quality forgings with excellent mechanical properties.
